Ezviz H90 Dual 4MP⁺ 4MP ⁺ Dual-Lens Pan & Tilt Wi-Fi Camera

General

Brand

EZVIZ

Model

CS-H90

Illuminator

IR Distance

30 m (98 ft)

Camera Feature

Button

Reset Button

Effective Pixels

4MP+4MP

Frame Rate

Self-adaptive during network transmission

Illumination

0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

Max. Resolution

2K+ (2560 × 1440)

Pan & Tilt

Top Lens: Pan: 220°, Tilt: 10° (manual adjustment for vertical angle ) Bottom Lens: Pan: 324°, Tilt: 90°

Storage Type

Micro SD card slot (Max. 512GB)

Wired Network

RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Wireless Network

Wi-Fi Standard-IEEE802.11b, 802.11g, 802.11n Frequency Range-2.4 GHz ~ 2.4835 GHz Channel Bandwidth-Supports 20MHz Security-WPA-PSK/WPA2-PSK Transmission Rate-11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps Wi-Fi Pairing-AP paring Protocol EZVIZ-cloud proprietary protocol Interface Protocol-EZVIZ cloud proprietary protocol

Image Sensor

1/3″ Progressive Scan CMOS

DNR

3D DNR

WDR

Digital WDR

Smart Alarm

Motion Detection, Human Detection, Human Tracking, Noise Detection, Auto Patrol

Lens

Field Of View

Diagonal 110°, Horizontal 96°, Vertical 54°

Others

Weatherproof Design Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Lens

Top Lens: 2.8mm @ F1.6, Field of view : Diagonal 110°, Horizontal 96°, Vertical 54° Bottom Lens: 6mm @ F1.6, Field of view : Diagonal 60°, Horizontal 52°, Vertical 28°

Power

Power Supply

IP65 + 2h rainstorm

Power Consumption

MAX. 18W

Video Features

Bit Rate

Quad HD; Full HD; Standard adaptive bit rate

Video Compression

H.265 / H.264

Physical Specification

Color

White

Operating Temperature

-30°C to 50°C ( -22 °F to 122 °F )

Others

Humidity 95% or less (non-condensing)

Weight

1203 g (42.43 oz)

Dimension

224 × 135 × 136 mm (8.82 × 5.31 × 5.35 inch)

Warranty Information

Warranty

01 Year Warranty
