A3399 Digital Clamp Multimeter Ammeter A3399 Clamp Meter A3399 Multifunctional Digital Clamp Meter DC AC Voltage AC Current Resistance Capacitance Frequency Testers

Description: A3399 Clamp Meter

A3399 Clamp Meter A3399 Multifunctional Digital Clamp Meter DC AC Voltage AC Current Resistance Capacitance Frequency Tester A3399 Digital Clamp Multimeter Ammeter

A3399 meter is multifunctional handheld and battery operated Digital Clamp Meter (DCM). A3399 DCM, with stable performance, reasonable structure, high precision of the whole A / D converter as its core, can detect non-contact NCV voltage, DC and AC voltage, DC current and AC current, resistance, capacitance, frequency, measurement parameters temperature, diode. With its high reliability, the DCM is to give your work efficiency and convenience. The unit has a backlight, which can help the user clearly read the measured value display in low-light settings. It’s a superior performance electrician special instruments.

A3399 meter is multifunctional handheld and battery operated Digital Clamp Meter (DCM). A3399 DCM, with stable performance, reasonable structure, high precision of the whole A / D converter as its core, can test DC and AC voltage, AC current, resistance. With its high reliability, the DCM is to give your work efficiency and convenience.

Features:

• Data hold function.
• Low voltage indication.
• Temperature measurement.
• A superior performance electrician special instruments.
• Overload protection, full range protection.
• Back light, helps the user clearly read the measured value display in low-light settings.
• Low battery indication.
• Input polarity: Display.
• Relative mode measurement.
• The DCM as general measurement tool is widely used in the laboratory, factory, radio amateurs and one family required meter outdoors.
• Stable performance, reasonable structure, high precision of the whole A / D converter as its core
• Scope of application: Office, Industrial, Agricultural, Home appliance, Education
• LCD full scale display “OL”
• Max. Jaw size φ21mm , Max Hold , Data Hold freezes reading on display , Auto Range , Full range overioad protection , Auto Power off , Low Battery Indicator , Diode Test , Continuity Check

Specifications:

• Brand: HONEYTEK / KD / Any
• Model: A3399 / KD3399
• Material: ABS
• Type: Measuring instruments
• Certificate: CE
• Item Type: Clamp Meter
• Maximum Number of Displays: 1999
• DC Vol e: 200mV / 2V / 20V / 200V / 600V ¡À (0.5% + 3)
• AC Vol e: 2V / 20V / 200V / 600V ¡À (1.0% + 3)
• AC Current: 2A / 20A / 200A / 500A (For Clamping), ¡À (2.5% + 3)
• Resistance: 200¦¸/ 2K¦¸/ 20K¦¸/ 200K ¦¸/ 2M¦¸/20M¦¸, ¡À(1.0% + 2)
• Color: Any
• Safety Level: CAT III 600V
• Weight: Approx. 210g / 7.4oz
• Maximum Jaw Diameter: Approx.21mm / 0.8in
• Battery Type: 3 x 1.5V AAA Batteries (Batteries Not Included)

Professional instruments: Multimeter

Primary functions: Detect non-contact NCV voltage, DC and AC voltage, DC current and AC current, resistance, capacitance, frequency, measurement parameters temperature, diode

How to Use:

The maximum display number of this automatic range digital clamp meter is 2000, DC vol e is 600V, AC vol e: 600V, AC current is 2A\u2011500A, and resistance is 20M¦¸. The instrument has functions of on\u2011off beep, data retention, and automatic shutdown Full range overload protection, low vol e display, maximum hold, diode test, automatic shutdown
