• Input Range: 3V ~ 32V
• Output Range: 5V~35V
• Input Current: 4A ( max ) , no-load 18mA (5V input , 8V output , no-load is less than 18mA.
• Higher the voltage , the greater the load current . )
• Conversion efficiency: < 94% ( greater the pressure , the lower the efficiency )
• Switching frequency: 400KHz
• Output Ripple: 50mV ( the higher the voltage , the greater the current , the greater the ripple )
• Load Regulation: ± 0.5%
• Voltage Regulation: ± 0.5%
• Operating Temperature: -40 ℃ ~ +85 ℃
